Huawei AirEngine 5760-51 Indoor Wi-Fi 6 AP, 5.37 Gbps, Dual/Triple-Radio
Huawei AirEngine 5760-51: Wi-Fi 6 Access Point with 5.95 Gbps Speed, 8x8 MIMO
The Huawei AirEngine 5760-51 is a next-generation Wi-Fi 6 (802.11ax) indoor access point designed to deliver high-performance and high-density wireless connectivity.
It supports flexible switching between dual-radio and triple-radio modes, making it ideal for enterprise offices, educational institutions, and high-traffic public spaces.
Overview
Highlights
-
Flexible Radio Configuration: Supports both dual-radio and triple-radio modes, allowing adaptation to varying network demands. In dual-radio mode, it offers 2.4 GHz (2x2 MIMO) and 5 GHz (4x4 MIMO) configurations. In triple-radio mode, it provides 2.4 GHz (2x2 MIMO), 5 GHz-0 (2x2 MIMO), and 5 GHz-1 (2x2 MIMO) configurations.
-
High Throughput: Delivers a maximum data rate of up to 5.37 Gbps in its basic configuration. With an RTU (Right to Use) license, it can achieve up to 5.95 Gbps, accommodating high-density environments and bandwidth-intensive applications.
-
Smart Antenna Technology: Equipped with built-in smart antennas that dynamically adjust signal coverage, enhancing signal quality and reducing interference.
-
IoT Integration: Features built-in IoT slots and supports BLE 5.0, enabling seamless integration with various IoT devices and protocols such as RFID and ZigBee.
-
Advanced Security: Supports WPA3 encryption, 802.1X authentication, and rogue device detection, ensuring robust network security.
-
Versatile Management: Compatible with Huawei’s CloudCampus platform and supports multiple management modes (Cloud / Fit / Fat) for simplified operations and maintenance.
Recommended Accessories
| Product Model | Category | Description |
|---|---|---|
| AP5760-51 | Access Point | Main unit with built-in smart antennas and IoT expansion slots |
| L-AP5760-51-1 | AP Resource License | License for managing 1 AP |
| L-AP5760-51-10 | AP Resource License | License for managing 10 APs |
Comparison with Similar Models
| Model | Max Managed APs | Forwarding Capacity | Ports |
|---|---|---|---|
| AirEngine 5760-51 | 1,152 | 5.95 Gbps | 1 × 5GE, 1 × GE (RJ45), 1 × USB |
| AirEngine 5760-10 | 512 | 1.774 Gbps | 2 × GE (RJ45), 1 × USB |
| AirEngine 5760-22W | 512 | 1.774 Gbps | 2 × GE (RJ45), 1 × USB |
| AirEngine 5761-11 | 512 | 2.4 Gbps | 2 × GE (RJ45), 1 × USB |
| AirEngine 5762S-12 | 512 | 1.774 Gbps | 2 × GE (RJ45), 1 × USB |
Specification
| Parameter | Specification |
|---|---|
| Model | AirEngine 5760-51 |
| Wi-Fi Standards | IEEE 802.11a/b/g/n/ac/ac Wave 2/ax |
| Radio Configuration | Dual-radio: 2.4 GHz (2x2 MIMO), 5 GHz (4x4 MIMO); Triple-radio: 2.4 GHz (2x2 MIMO), 5 GHz-0 (2x2 MIMO), 5 GHz-1 (2x2 MIMO) |
| Peak Data Rate | Up to 5.37 Gbps (basic); up to 5.95 Gbps (with RTU license) |
| Ethernet Ports | 1 × 5GE and 1 × GE electrical ports |
| Antenna Type | Built-in smart antennas |
| Power Supply | DC: 48 V ±10%; PoE: IEEE 802.3bt compliant |
| Maximum Power Consumption | Not specified |
| Security | WPA3, WPA2, WPA, 802.1X, rogue device monitoring |
| Management | Cloud, Fit, and Fat modes; compatible with CloudCampus |
| Operating Temperature | –10°C to +50°C |
| Storage Temperature | –40°C to +70°C |
| Operating Humidity | 5% to 95% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (Diameter × Height) | 220 mm × 50 mm |
| Weight | Not specified |
| Warranty | Limited lifetime warranty |
