NSComm S5624X-8N-EI 24-Port 10G + 8-Port 25G L3 Data Center Switch
NSComm S5624X-8N-EI 24-Port 10G + 8-Port 25G L3 Data Center Switch
Overview
The NSComm S5624X-8N-EI is a high-performance Layer 3 managed switch for 10G optical access and 25G aggregation. It provides 24 x 10GE SFP+ ports and 8 x 25GE SFP28 uplink ports in a compact 1U platform.
Built on the VastLakes platform, the NSComm S5624X-8N-EI delivers 880 Gbps bidirectional switching capacity and 1309.44 Mpps bidirectional forwarding performance, with dual hot-swappable CRPS power modules and two hot-swappable fan modules for resilient deployment.
Core Highlights
- 10G optical access: 24 x 10GE SFP+ ports for server, storage, or aggregation links
- 25G uplinks: 8 x 25GE SFP28 ports for higher-bandwidth aggregation
- Performance: 880 Gbps switching capacity and 1309.44 Mpps forwarding
- Platform: VastLakes with dual-core ARM A53 1.2GHz CPU, 2GB DRAM, and 8GB eMMC
- Resilience: Dual 350W CRPS power modules and 2 hot-swappable fan modules
- PoE: None
Application Scenarios
- 10G server access and 25G uplink aggregation
- Enterprise data-center leaf, HCI, and metro aggregation
- High-bandwidth campus or government network aggregation
Comparison with Similar Models
| Model | Ports | PoE | Uplink | Best For |
|---|---|---|---|---|
| NSComm S5624X-8N-EI | 24 x 10GE SFP+ | None | 8 x 25GE SFP28 | 10G/25G aggregation |
| Cisco C9500-24Y4C | 24 x 1/10/25GE SFP28 | None | 4 x 40/100GE QSFP28 | Campus core and aggregation |
| Huawei S6730-H24X6C | 24 x 10GE SFP+ | None | 6 x 40/100GE QSFP28 | Enterprise aggregation |
Specifications
| Ports | 24 x 10GE SFP+ |
| Uplink Ports | 8 x 25GE SFP28 |
| PoE | None |
| Switching Capacity | 880 Gbps bidirectional |
| Forwarding Rate | 1309.44 Mpps bidirectional |
| Packet Buffer | 4.5MB default / 9MB extended |
| CPU | Dual-core ARM A53 1.2GHz |
| Memory / Flash | 2GB DRAM / 8GB eMMC |
| Power | 350W / 350W CRPS, dual hot-swappable AC or DC power modules |
| Cooling | 2 hot-swappable fan modules, front-to-back airflow |
| Dimensions | 44.2 x 4.4 x 35.7 cm |
| Package Dimensions | 55.7 x 15 x 49.5 cm |
| Weight | 5 kg net / 8.5 kg gross |
| Operating Temperature | 0 to 45 degrees C |
| Management | RJ45 console, 1G out-of-band Ethernet, in-band network ports, USB, CLI, web, SNMP, Telnet, FTP, SSH2.0, SSL |
| Software Features | IPv6, OSPF, BGP, PIM, MPLS L2/L3 VPN, VPLS, VXLAN, MACsec, PTP, ERPS, QoS, ACL, OAM, VRRP |
| Software Platform | Vastlakes Platform |
Why Choose NSComm S5624X-8N-EI?
- Balanced 24-port 10G access with 8-port 25G uplink capacity
- Advanced Layer 2/Layer 3, MPLS, VXLAN, MACsec, and PTP support
- Dual CRPS power and hot-swappable fans for enterprise deployment
- Compact 1U form factor for data-center, campus, HCI, and metro aggregation networks
